Input Power:
Voltage: 24V DC Nominal (18-30 V DC)
Current @ 24 VDC: 220 mA nominal, 295 mA in alarm
Dimensions (W x H x D):
256mm x 183mm x 92mm
Mounting:
Upright, inverted or horizontal
Operating Conditions:
Ambient: 0°C to 39°C
Tested to (EN54-20): -10°C to 55°C
Sampled Air**: -20°C to 60°C
Humidity: 5% to 95% RH, non-condensing
Sampling Network:
Maximum pipe lengths: 1 x 25m (Max. 12 holes) 2 x 15m per branch (Max. 6 holes per branch)
Sampling Hole Options: Pre-Engineered Option or Maximum Pipe length in accordance with Pipe Modelling Design Tool (ASPIRETM)
Alarm Threshold Setting Range:
Alert, Action: 0.025 - 2.00% obs/m
Fire 1, Fire 2: 0.025 - 20.00% obs/m
Individual Alarm Delays: 0 – 60 seconds
Two Alarm Threshold Settings: Either time or GPI based
