Specifications:
Power Source: SensorGateway (BASE-WIRED)
Power Usage: 588mW
Expansion ports for external sensor probes: 8
Dry contact input ports: 4
Dry contact output ports: 4 (digital sink 100mA)
Built-in alerting options: Email, SMS (over IP) & SNMP Traps
Relay outputs: 2 (400VAC/150VDC and 200VA/192W)
Auxillary supply: Maximum current capacity of 500mA at 9 to 12 VDC
Environmental and Physical Specification:
Operating temperature range: 0ºC to +75ºC
Operating Humidity Range: < 90% rH (non-condensating)
Dimensions: 165mm x 95mm x 22mm
Weight: 0.57kg
