Electrical Specifications:
Supply Voltage: 24Vdc (18 - 30Vdc)
Maximum Power Consumption: Single Channel Model: 400mA @24Vdc
Dual Channel Model: 450mA @24Vdc
Relays: 3 per channel, Action, Alarm and Fault 2A @30V
Detector Sensitivity Range: 0.05%obs/m to 6.56%obs/m
Environmental Specifications:
Operating Temperature: -40°C to 55°C
Sampled Air Temperature: -40°C to 55°C
Humidity: 10-93% RH
Ingress Protection Rating: IP40
General Specifications:
Flow Sensor Number: 1 per channel
Level of Alarm: Action and Alarm per channel
Fan Setting: Adjustable
Area Coverage:
Single Channel Model: 1,600m2
Dual Channel Model: 2,000m2
Pipe Network Layout (Single Channel Model:):
Linear pipe length: 1 x 105m
Branch pipe length: 2 x 105m; 4 x 68m
Pipe Network Layout (Dual Channel Model):
Linear pipe length: 2 x 105m
Branch pipe length: 4 x 105m; 8 x 49m
Sampling Holes:
Single Channel Model: A, B, C: 5, 15, 32
Dual Channel Model: A, B, C: 8, 28, 56
General Purpose Input (GPI): Reset, Disable, External Fault
Out-of-Box Configuration: DIP Switches
Field Replaceable Components: Sensing Module, Metal Filter, Front Cover, Aspirator, Internal Covers and Adaptor Set
Data Logging: Device Info, Device Configuration, Device Status Logged Events and Data
Communication: USB & Bluetooth
Warranty: 3 years
